SIZE:80x80x38mm
CONSTRUCTION:Glass Fiber reinforced plastic; Impeller and housing PBT are UL 94V-0 rating
OPERATING TEMPERATURE:Ball bearing -10℃ to +70℃;Sleeve bearing -10℃ to +60℃
INSULATION RESISTANCE:10meg Ohm min, at 500 VDC(between frame and terminal)
DIELECTRIC STRENGTH:1mA max, at 2000 VAC 1 minute(between frame and terminal)
FUNCTION OPTIONS:FG,RD, PWM,Auto Restart, Polarity Protection
| Model |
Bearing Type |
Rated Voltage |
Power | Speed |
Air Flow |
Static Pressure |
Noise Level |
Weight |
| VAC | W | RPM | CFM | mmH₂O | dBA | g | ||
| YEH8038×2 | s orB | 110/220 | 5.0 | 4000 | 49.42 | 9.50 | 45.58 | 154 |
| YEM8038×2 | sorB | 110/220 | 4.0 | 3200 | 39.54 | 6.08 | 40.25 | 154 |
| YEL8038x2 | S orB | 110/220 | 3.0 | 2500 | 30.89 | 3.71 | 34.36 | 154 |
1.Specifications subject to change without notiec;
2.Design and provide products according to client’s requirements.
